Product Details:
|
| Material: | Polycarbonate(PC) | Color: | Yellow, Bronze, Pink |
|---|---|---|---|
| Thickness: | 1.5mm~10.0mm | Width: | 1220mm, 1560mm, 1820mm, 2100mm, Customized |
| Length: | 2440mm, 3000mm, 5800mm, Customized | Standard Size: | 1220*2440mm, 2000*3000mm, 2100*5800mm |
| Fire Rating: | UL94 V-2, UL94 V-0 | UV Protection: | 50 Micron UV Resistance |
| Service Life: | Above 10 Years | Transport Package: | PE Protective Film, Kraft Paper |
| Brand Of Raw Material: | Covestro, , | HS Code: | 3920610000 |
| High Light: | 1220*2440mm embossed polycarbonate solid sheet,Lichee Pattern pc embossed sheets,embossed polycarbonate solid sheet ASTM D648 |
||
High Quality Building Material Embossed Polycarbonate Solid Sheet
DESCRIPTION
SHENGHANG PLASTIC Embossed Polycarbonate Solid Sheet is a branch of solid polycarbonate sheets and it is a one-sided solid sheet with the grain. The grain on the surface can play the role of ground glass, enhance the masking and concealment. What's more, the grains can diffuse and scatter the strong light directly, make the light soft and uniform, and effectively reduce glare and light pollution.
PRODUCT ADVANTAGES
* High impact strength - Unbreakable
* Strong weather resistance
* Lightweight
* Good flame retardancy
* Good thermal insulation
* Waterproof
* Fine plasticity
* Good processability
* Unique textured surface - Privacy protection
SPECIFICATIONS
*Thickness: 1.5mm~10.0mm (Main Thicknesses: 1.5mm/1.8mm/2.0mm/2.5mm/3.0mm/4.0mm/5.0mm/6.0mm)
*Width: Max. 2100mm(1220/1560/1820/2100mm/customized)
*Length: 2440mm/3000mm/5800mm/30 meters per roll/customized
*Normal Size: 1220*2440mm, 2000*3000mm, 2100*5800mm
*Colors: Transparent(clear), brown, lake blue, blue, green, opal white, grey, black, yellow, orange, red, pink, customized
| FEATURES | TEST METHOD | TEST CONDITION | UNIT | DATA |
| Density | ASTM D-792 | g/cm3 | 1.2 | |
| Heat Deflection Temperature | ASTM D-648 | Load:1.82 MPa | ºC | 135 |
| Short-term Service Temperature | ºC | -50~+120 | ||
| Long Service Temperature | ºC | -50~+100 | ||
| Linear Expansion Coefficient | ASTM D-696 | cm/cmºC | 6.5x10-5 | |
| Thermal Conductivity | ASTM C-177 | W/m K | 0.21 | |
| Yield Tensile Strength | ASTM D-638 | 10mm/min | Mpa | 62 |
| Tensile Strength at Break | ASTM D-638 | 1mm/min | Mpa | 65 |
| Yield Elongation | ASTM D-638 | 10mm/min | % | 6 |
| Elongation at Break | ASTM D-638 | 10mm/min | % | >70 |
| Elastic Tensile Modulus | ASTM D-638 | 1mm/min | Mpa | 2300 |
| Bending Strength | ASTM D-790 | 1mm/min | Mpa | 93 |
| Flexural Modulus | ASTM D-790 | 1.3mm/min | Mpa | 1890 |
| Shock Drop | (ISO 6603/1 E50) | 0.8mm sheet | J | 50 |
| Rockwell Hardness | ASTM D-785 | R Scale | 118 | |
| Light Transmittance | ASTM D-1003 | Transparent | % | 90% |
| Haze | ASTM D-1003 | Transparent | % | <0.5 |
| Yellowing Index | ASTM D-1003 | Transparent | YI | <1 |
FEATURES
1) Good light transmission: reaches 12%- 92% depending on color and thickness
2) Impact resistance: 250-300 times that of ordinary glass and 20-30 times that of acrylic sheet
3) Weather resistance: applicable temperature -40°C ~+120°C
4) Fire resistance: UL94 V-2, UL94 V-0, ASTM E84 CLASS A
5) Lightweight and easy installation: 1/2 of glass based on the same thickness
6) Ultraviolet resistance: 50um~80um one side or both sides anti-UV coating
7) Sound insulation and noise reduction: 5mm sheet attenuate 23db, 10mm sheet attenuate 35db
8) Heat insulation: heat Conductivity - 0.2 W/m2· K
9) Fine plasticity: Suitable for processing such as carving, drilling, cutting, bending, hot forming, printing, etc.
PRODUCT SHOW
PRODUCT CATEGORIES
PROCESSING SERVICE
Polycarbonate sheet has excellent dimensional stability, which is very suitable for secondary processing. Its processed products are widely used in industry, security, construction, new energy vehicles, and many other industries.
We provide professional customized plastic sheets especially polycarbonate sheet and acrylic sheet processing services, including machining, carving, engraving, precision cutting, bending, welding, polishing, milling, drilling, trimming, thermoforming, silk screen printing, and so on.
Welcome to provide drawings or samples, communicate and confirm the processed products. As for customized products, our minimum order quantity is 1 piece. You can cooperate with us for batch orders after the samples are checked and qualified.
FACTORY TOUR
TYPICAL APPLICATIONS
1) Unusual decorations, corridors and pavilions in gardens and recreational and rest places;
2) Interior and exterior decorations of commercial buildings, and curtain walls of the modern buildings;
3) Advertising light box, telephone booths, street name plates and sign boards;
4) Lighting materials, walls, roofs, doors and windows, screens, skylight;
5) Sound insulation shields(acoustic barrier) on express ways and city overhead highways;
6) Ceiling material for awnings, canopy, carport, balcony.
