UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored

Certification
China Anhui Shenghang Plastic Co., Ltd. certification
I'm Online Chat Now

UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored

UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored
UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored

Large Image :  UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored

Product Details:
Place of Origin: China
Brand Name: SHENGHANG PLASTIC
Certification: SGS
Model Number: SH-HS2R-GS07
Payment & Shipping Terms:
Minimum Order Quantity: 500 Square Meters
Price: Negotiable
Packaging Details: PE Protective Film
Delivery Time: 7~10 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 8500 Tons/Year

UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored

Description
Material: Polycarbonate(PC) Thickness: 4mm, 5mm, 6mm, 8mm, 10mm
Width: 2100mm, Customized Length: 3000mm, 6000mm, Customized
Standard Size: 2100*3000mm, 2100*6000mm Color: Clear, Colored
Structure: Double-wall Rectangular Structure UV Protection: 50um Anti-UV Coating
Service Life: Above 10 Years Transport Package: PE Protective Film
Brand Of Raw Material: Covestro, , Fire Rating: UL94 V-2, UL94 V-0
HS Code: 3920610000 OEM: Acceptable
High Light:

UL94 V0 bronze twinwall polycarbonate

,

10mm bronze twinwall polycarbonate sheet Colored

,

6mm bronze twinwall polycarbonate sheet



High Impact Strength Plastic Roof Panel Twin Wall Polycarbonate Sheet



DESCRIPTION

SHENGHANG PLASTIC Polycarbonate hollow sheet has many characteristics, such as light weight, easy installation, high impact strength, thermal insulation, long service life and so on. The surface of the polycarbonate sheet is coated with an anti ultraviolet coating, which can effectively block the ultraviolet radiation in the sunlight. This ensures that the internal molecular structure of the polycarbonate sheet is not damaged, so that the service life of the sheet can be more than ten years.


PRODUCT ADVANTAGES
*Lightweight
*High impact strength
*High light transmittance
*UV protection
*Strong weather resistance
*Good thermal insulation
*Easy to install and process

*Customized size and color





SPECIFICATIONS
1) Thickness: 4mm~12mm(4mm, 5mm, 6mm, 8mm, 10mm)
2) Standard size: 2100*6000mm, 2100*5800mm

3) Colors: Transparent(clear), Bronze, Green, Blue, Lake blue, White, Gry, Silver, Yellow, Orange, Red, Customized.
4) The color and size of twin-wall polycarbonate sheets can be customized.
5) Both sides of polycarbonate hollow sheets are covered with PE protective film. The Printing(logo and brand) on the PE film can be customized.



Structure Model Thickness Weight Max Width Anti-UV Coating Max Light Transmission K Value Min. Bend Radius Color
(mm) (kg/m2) (mm) (um) (%) (W/M2K) (mm)
Twin-wall HS2R 4 1.0 2100 50 82 4.00 700 Clear,
White,
Bronze,
Blue,
Lake blue,
Green,
Yellow,
Orange,
Red,
Pink,
Silver,
Gray,
Black…
6 1.3 2100 50 81 3.60 1050
8 1.5 2100 50 80 3.30 1400
10 1.7 2100 50 79 3.00 1750
12 1.9 2100 50 79 2.80 2100
3-wall HS3R 6 1.4 2100 50 76 3.22 1050
8 1.6 2100 50 72 2.92 1400
10 1.8 2100 50 68 2.70 1750
12 2.1 2100 50 66 2.60 2100
14 2.3 2100 50 65 2.40 2450
16 2.5 2100 50 63 2.27 2800
3-wall X HS3R-X 12 2.3 2100 50 65 2.55 2100
14 2.5 2100 50 64 2.36 2450
16 2.7 2100 50 63 2.20 2800
18 2.9 2100 50 62 2.12 3150
4-wall HS4R 8 1.8 2100 50 68 2.56 1400
10 1.9 2100 50 67 2.39 1750
12 2.0 2100 50 65 2.30 2100
14 2.2 2100 50 64 2.10 2450
16 2.4 2100 50 63 2.00 2800
18 2.6 2100 50 62 1.88 3150
Honeycomb HS4H 6 1.5 2100 50 59 2.83 1050
8 1.8 2100 50 58 2.48 1400
10 2.0 2100 50 57 2.16 1750
12 2.2 2100 50 56 1.98 2100
5-wall HS5R 8 1.8 2100 50 65 2.53 1400
10 2.0 2100 50 64 2.30 1750
12 2.2 2100 50 63 2.26 2100
5-wall X HS5R-X 16 2.5 2100 50 61 1.89 2800
18 2.8 2100 50 60 1.78 3150
20 3.2 2100 50 59 1.69 3500
25 3.5 2100 50 57 1.50 4375
30 4.0 2100 50 55 1.35 5250
6-wall Diamond HS6D 12 2.2 2100 50 61 2.17 2100
14 2.5 2100 50 60 1.90 2450
16 2.9 2100 50 59 1.84 2800
18 3.0 2100 50 58 1.72 3150
7-wall HS7R 14 2.4 2100 50 58 1.80 2450
16 2.6 2100 50 56 1.66 2800
18 2.8 2100 50 54 1.52 3150
20 3.0 2100 50 52 1.38 3500
22 3.2 2100 50 50 1.24 3850
8-wall
Diamond
HS8D 25 3.4 2100 50 48 1.40 4375
32 3.6 2100 50 46 1.28 5600
35 4.0 2100 50 44 1.19 6125
40 4.5 2100 50 42 1.10 7000





PRODUCT SHOW

UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored 0



UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored 1



UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored 2




COLOR SELECT

UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored 3


PRODUCT CATEGORY

UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored 4



FEATURES

1) Lightweight: Only 1/12 of the weight of glass of the same thickness

2) High impact strength: 80 times that of glass, 15 times that of acrylic sheet

3) Fire resistance: UL94 V-2, UL94 V-0

4) Good light transmittance: Up to 85%

5) Ultraviolet resistance: 50~80um UV coating

6) Excellent physical, mechanical, and electrical properties

7) Weather resistance: -40°C ~+120°C

8) Excellent thermal insulation performance



OPTIONAL FUNCTIONS
1. Anti-drip
The new generation of the anti-drip sheets is made of hydroxyl-coated nano-silicone anti-fogging material imported from the original. This hydrophilic anti-fogging material can increase the tension of water vapor on the surface of the polycarbonate sheet. Its typical contact angle of water droplets can be as low as 8 degrees. The water droplets formed by the accumulation of fog will quickly distribute downward along the slope of the inner wall of the polycarbonate sheet. It is suitable for lighting roofs that do not allow droplets, especially for swimming pools, agricultural greenhouses, and plant ecological gardens.

2. Frosted
The twin-wall polycarbonate sheet is modified by a special BAYER brilliant masterbatch while maintaining high transmittance. Its inner wall particle effect changes the glare band formed by light refraction of
ordinary board, so that the sunlight becomes soft and does not glare.



FACTORY TOUR

UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored 5

UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored 6




TYPICAL APPLICATIONS
1. Awning for the stadium, bus stop, airport.

2. Lighting system for passage, walkway, the entrance of subway.

3. Agriculture greenhouse, canopy for vegetables, animals, flowers.

4. Heat insulation, soundproof for expressway, buildings.

5. Bus stop, advertising lamp box, canopy for ATM.

6. Lighting decoration for the workshop, commercial canopy, villas.

7. Lighting system for skylight, cellar, dome.

8. Decoration panel for inner/outer wall, roof.


PACKING & SHIPPING

UL94 V0 6mm 10mm Bronze Twinwall Polycarbonate Sheet Colored 7



LOADING QUANTITY OF CONTAINER

Thickness(mm) Specification(mm) Quantity for 20GP Specification(mm) Quantity for 40HQ
(PCS) (PCS)
4 2100*5800 550 2100*6000 1300
6 2100*5800 380 2100*6000 880
8 2100*5800 290 2100*6000 670
10 2100*5800 235 2100*6000 535
